Medfusion 3500 Syringe Pump 4.1.5

Original price was: $1,595.Current price is: $1,295.

An ambulatory syringe pump that runs on either AC current or on rechargeable internal batteries.

Click here for version 3.06

Click here for version 5.0



SKU: 3500-415 Category: Brand:
No Sales Tax
1 year warranty on equipment orders
Commercial financing available for orders over $2,000

Medex Medfusion 3500 Syringe Pump

Smiths medical part# 3500-415

Refurbished Patient ready with 1 year warranty

Pole clamp included



The Medfusion 3500 Syringe Pump software 4.1.5 is an ambulatory syringe pump that runs on either AC current or on rechargeable internal batteries.  This pump may be used in MRI rooms and utilizes an interface that is easy to program and use.  It is user friendly with single-handed loading and a stackable horizontal design, mounting easily to an IV pole, an infant’s isolette or radiant warmer. Medfusion® 3500 syringe infusion pump is chosen by the top pediatric and general hospitals for arterial, epidural, enteral, intravenous, spinal and subcutaneous medication delivery. The syringe pump was designed for the administration of fluids requiring precisely controlled infusion rates. It is widely recognized for its accurate medication delivery to patients in critical care units, including neonatal and pediatric intensive care. Medfusion® syringe pumps automatically detect syringe sizes from 1 mL to 60 mL including intravenous and enteral syringe types from the most common manufacturers.

Safe.

  • With a large display screen that is especially easy to read in high or low light conditions, Medfusion® 3500 Syringe pump can be safely used throughout the hospital or during patient transport
  • Easy occlusion detection using FlowSentry™ enhances pressure trending
  • Long lasting internal battery capacity of 10 hours (at 5.0 mL/hr with 60 mL syringe)
  • Wide Ranging flow rates and the capacity to infuse at low rates with larger syringes

Simple.

  • Start an infusion in as few as 3 button presses
  • Unique, easy-to-use, and easy-to-learn workflow of the Medfusion® 3500 syringe pump is complemented by the small, lightweight, ergonomic and portable pump design.
  • The horizontal design protects entire syringe barrel and allows single-handed syringe loading
  • On-board biomed capabilities for preventive maintenance dates, viewing service history and accessing calibration and diagnostic testing information
Weight 6.00 lbs
Dimensions 16.00 × 8.00 × 8.00 in

Reviews

There are no reviews yet.

Be the first to review “Medfusion 3500 Syringe Pump 4.1.5”

CADD Solis Specifications

Dimensions

  • Size: 4.1 cm x 10.2 cm x 12.7 cm (1.6 in x 4 in x 5in)
  • Weight: 595g (21 oz) including 4 AA Alkaline batteries

Resolution

  • CADD medication cassette reservoir: 0.05 mL per pump stroke nominal
  • CADD administration set: 0.05 mL per pump stroke nominal
  • CADD high volume administration set: 0.1 mL per pump stroke nominal

System Temperatures

  • Operating Temperature: 2°C to 40°C 36°F to 104°F
  • Storage and transportation Temperature: –20°C to 60°C –4°F to 140°F
  • Maximum surface temperature (while operating): 48°C (118°F) Maximum
  • Moisture Protection: Splashproof (E) per IEC 60529
  • Relative Humidity: y 20% to 90% relative humidity, non-condensing
  • Atmospheric Pressure: 70 kPa to 106 kPa 10.2 psi to 15.4 psi

Power

  • Power Source:
    • AC adapter
    • CADD-Solis rechargeable battery pack
    • CADD-Solis Communication Module with integrated rechargeable battery
    • Four AA alkaline batteries (for example, Duracell PC1500 / MN1500, IEC LR6)
  • charging system for internal memory backup battery: The internal memory backup battery uses lithium manganese dioxide technology. It charges whenever the pump is powered on and has a 10-month memory capacity once it has been charged for 250 hours at 20°C (68°F).
  • Battery Fallot alarm: The alarm sounds for at least 2 minutes if the pump has been powered up for a minimum of 4 minutes. Note: Alarm enabled while the pump is in run mode only.

smiths-medical-cadd-solis-operators-manualClick here to download the PDF file.
